The FA-ST 1888SH High Viscosity Oil Filter Cartridge is your go-to solution for basic filtration needs in high viscosity oils, designed to fit seamlessly into the 9788/KU85 filter housing used in most of our filtration systems. Engineered with an outer cardboard sleeve, this filter prevents back pressure build-up by creating an area where oil can bypass the cartridge, ensuring a continuous flow.
While the bypass feature maintains flow, it comes with the trade-off that the oil bypassing the cartridge remains unfiltered, retaining particulate contaminants. For effective gear oil filtration, we recommend using the 1888SH for initial filtration to remove most contaminants, followed by our premium high viscosity filter to achieve the desired cleanliness level.
Applied to wind turbines, transmissions, gearboxes, and applications using oil between 120-460 viscosity, the 1888SH filter cartridge is ideal for engines with sump capacities of 18 gallons/90 litres or hydraulic systems with tanks up to 300 gallons/1360 litres. Crafted from tightly wound filter media, a 1-micron 2mm base layer, and a cardboard outer sleeve with handles, this cartridge ensures reliable filtration in various temperature conditions. From light oils and diesel fuels to warm/hot oils up to 460 viscosities, the 1888SH filter cartridge delivers versatile and essential filtration for your machinery. Explore our range now to enhance your oil filtration process.
Dirt retention capacity:
Size: Diameter: 198mm Height: 105mm.
The 1888SH High Viscosity Oil Filter Cartridge Filtration Summary
Filtration Of | Suitability | Comments |
Hydraulic Oil | |
These filters will provide filtration of hydraulic oils however the bypass feature means filtration is less efficient and better options are available |
Diesel Fuel | These filters will provide filtration of diesel fuel however the bypass feature means filtration is less efficient and better options are available | |
Engine & Other Lube Oils | These filters will provide filtration of engine & lube oils however the bypass feature means filtration is less efficient and better options are available | |
Coolant & Glycol | No These filters remove water and MUST NOT be used on water based fluids | |
High Viscosity Oil | These Filters are suitable for filtration on oils between 120 - 460 viscosity |
